Electric Contact Thermometer For On Point Control Bengaluru

Electric Contact Type Thermometer for Accurate Switching

We offer touch-sensitive (non-contact) thermometers that combine the accuracy of analog temperature measurement with the ease of electrical switching. These devices are ideal for monitoring and controlling temperature in heating and cooling systems and industrial processes.

Where Our Thermometers Are Used

Our contact thermometers are used in boilers, furnaces, oil baths, autoclaves, and HVAC systems. These products are used in a variety of industrial applications that require automatic temperature monitoring and adjustment at specific points.

How It Works

The system includes a bimetallic sensor or a gas-filled lamp connected to a thermometer. Electrical contacts are set to the desired upper and lower limits. Once the process temperature exceeds these limits, an internal switch activates alarms, relays, or shutdown procedures.

Core Features and Benefits

• Dual pointer system: actual reading + contact setting
• Rugged construction with SS casing and acrylic cover
• Adjustable contact range with micrometer screw
• Switch rating up to 250V AC / 5A
• Accuracy is typically within ±1.5% of full scale

Technical Parameters

• Measuring range: -40°C to 300°C (varies by model)
• Dial Size: 100 mm / 150 mm
• Mounting: Bottom or back flange
• Electrical connection: Terminal box or lead wire
• Optional: IP65 enclosure for outdoor use

Why Industries Prefer Our Devices

• Enables automated process protection
• Reduces reliance on external controllers
• Low maintenance with mechanical reliability
• Compatible with signal lights, buzzers, and PLCs
• Custom scale, mounting, and switch type available on request

Experience-Driven Supply

With our extensive experience in process measurement equipment, we offer thermometers that undergo rigorous contact switch testing and feature leak-proof insulation. We also calibrate each unit to ensure accurate control and long service life.
